pJB042 (FtsZ-mEos2)
(Plasmid #49764)

• Purpose: Inducible expression of FtsZ-mEos2 in bacteria
• Depositing Lab: Jie Xiao
• Publication: Buss et al Mol Microbiol. 2013 Sep;89(6):1099-120. doi: 10.1111/mmi.12331. Epub 2013 Aug 14.

Backbone

• Vector backbone: pCA24N
• Backbone manufacturer: NBRP-E.coli at NIG
• Backbone size w/o insert (bp): 4500
• Total vector size (bp): 6300
• Modifications to backbone: replaced N-terminal 6xHis with novel SpeI site, results in 6bp reduced expression
• Vector type: Bacterial Expression

Growth in Bacteria

• Bacterial Resistance(s): Chloramphenicol, 25 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Growth instructions: For fluorescence studies, grow at RT or 30C.
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: FtsZ-mEos2
• Species: E. coli
• Insert Size (bp): 1865
• Promoter: T5-lac
• Tag / Fusion Protein:
  • mEos2 (C terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: SpeI (not destroyed)
• 3′ cloning site: NotI (not destroyed)
• 5′ sequencing primer: GCGTAATAGCGAAGAGGCCCG
• 3′ sequencing primer: cattactggatctatcaacaggag

Resource Information

• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
