PurposeMammalian ST1-VP64 nuclease-null Cas9 activator expression, human optimized
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 48675 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepcDNA3.3 TOPO
-
Backbone manufacturerInvitrogen
- Total vector size (bp) 8998
-
Vector typeCRISPR
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameCas9-VP64, nuclease-null
-
SpeciesS. thermophilus #1
-
Insert Size (bp)3570
-
Mutationnuclease-null (D9A D598A H599A N622A)
- Promoter CMV
-
Tags
/ Fusion Proteins
- NLS (C terminal on insert)
- VP64 (C terminal on insert)
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer CMV-F
- 3′ sequencing primer TK-pA-R (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
M-ST1n-VP64 was a gift from George Church (Addgene plasmid # 48675 ; http://n2t.net/addgene:48675 ; RRID:Addgene_48675) -
For your References section:
Orthogonal Cas9 proteins for RNA-guided gene regulation and editing. Esvelt KM, Mali P, Braff JL, Moosburner M, Yaung SJ, Church GM. Nat Methods. 2013 Sep 29. doi: 10.1038/nmeth.2681. 10.1038/nmeth.2681 PubMed 24076762
