pEGFP-C1-FLAG
(Plasmid #46956)

• Purpose: Plasmid for cloning and expression of GFP-FLAG tagged proteins (N-terminal tag). Confers resistance to G418.
• Depositing Lab: Steve Jackson
• Publication: Britton et al J Cell Biol. 2013 Jul 29.

Backbone

• Vector backbone: pEGFP-C1
• Backbone manufacturer: Clontech
• Backbone size w/o insert (bp): 4731
• Total vector size (bp): 4766
• Modifications to backbone: Inserted a FLAG tag and XhoI and NotI unique restriction sites between BglII and HindIII.
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Kanamycin, 50 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): XL1 Blue
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: FLAG tag
• Species: Synthetic
• Insert Size (bp): 35
• Promoter: CMV

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: BglII (not destroyed)
• 3′ cloning site: HindIII (not destroyed)
• 5′ sequencing primer: CATGGTCCTGCTGGAGTTCGTG
• 3′ sequencing primer: GCAAGTAAAACCTCTACAAATGTGG

Resource Information

• Supplemental Documents:
  • Author annotated GenBank sequence
• Articles Citing this Plasmid:
  • 7 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
