pMA3379
(Plasmid
#46874)
-
PurposeA lentiviral vector for the doxycycline-inducible expression of soluble guanylate cyclase1 alpha3
-
Depositing Labs
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 46874 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepMA3211
-
Backbone manufacturerHomemade
- Backbone size w/o insert (bp) 6642
- Total vector size (bp) 8766
-
Vector typeLentiviral
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Stbl3
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namesoluble guanylate cyclase 1alpha3
-
SpeciesR. norvegicus (rat)
-
Insert Size (bp)2184
-
Entrez GeneGucy1a3 (a.k.a. Gucy1a1, SGC)
- Promoter TRE-Tight
-
Tag
/ Fusion Protein
- Myc (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site SalI (destroyed during cloning)
- 3′ cloning site NotI (destroyed during cloning)
- 5′ sequencing primer ctatagtgaatagagttagg (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made bycDNA was purchased from Open Biosystems
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please note that though there are some differences between Addgene's quality control sequence and the depositor's assembled sequence, this plasmid should function as reported.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pMA3379 was a gift from Mikhail Alexeyev & Troy Stevens (Addgene plasmid # 46874 ; http://n2t.net/addgene:46874 ; RRID:Addgene_46874) -
For your References section:
Pseudomonas aeruginosa exotoxin Y is a promiscuous cyclase that increases endothelial tau phosphorylation and permeability. Ochoa CD, Alexeyev M, Pastukh V, Balczon R, Stevens T. J Biol Chem. 2012 Jul 20;287(30):25407-18. doi: 10.1074/jbc.M111.301440. Epub 2012 May 25. 10.1074/jbc.M111.301440 PubMed 22637478
