pEGFPC1/GgVcl 1-1066 A50I K1306A, R1308A mutant
(Plasmid #46267)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 46267 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-C1
  • Backbone manufacturer
    Clonetech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 7990
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Vcl
  • Alt name
    Vinculin
  • Species
    G. gallus (chicken)
  • Insert Size (bp)
    3259
  • Mutation
    K1306A, R1308A, A50I mutation; talin binding deficient
  • GenBank ID
    NM_205441.1
  • Entrez Gene
    VCL (a.k.a. VINC1)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer EGFP-C
  • 3′ sequencing primer SV40pA-R
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Chicken vinculin, full length(EcoRI fragment of p1005 subcloned into EcoRI-cut pEGFP-C1); A50I mutation (alanine 50 to isoleucine) introduced by QCPCR.
This mutant binds poorly (undetectably to talin in pull down assays; sensitivity of assay Kd= 10-20 uM).

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFPC1/GgVcl 1-1066 A50I K1306A, R1308A mutant was a gift from Susan Craig (Addgene plasmid # 46267 ; http://n2t.net/addgene:46267 ; RRID:Addgene_46267)
