pEGFP-parkin C431S
(Plasmid #45877)

Print

Full plasmid sequence is not available for this item.

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 45877 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-C2
  • Backbone size w/o insert (bp) 4731
  • Total vector size (bp) 6129
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Parkin
  • Alt name
    PARK2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1398
  • Mutation
    C431S mutation (ubiquitin acceptor site)
  • GenBank ID
    NM_004562.2
  • Entrez Gene
    PRKN (a.k.a. AR-JP, LPRS2, PARK2, PDJ)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer EGFP_C_primer
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFP-parkin C431S was a gift from Edward Fon (Addgene plasmid # 45877 ; http://n2t.net/addgene:45877 ; RRID:Addgene_45877)

  • For your References section:

    Structure of Parkin Reveals Mechanisms for Ubiquitin Ligase Activation. Trempe JF, Sauve V, Grenier K, Seirafi M, Tang MY, Menade M, Al-Abdul-Wahid S, Krett J, Wong K, Kozlov G, Nagar B, Fon EA, Gehring K. Science. 2013 May 9. 10.1126/science.1237908 PubMed 23661642
