Addgene

pPAiRFP2-N1
(Plasmid #44273)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 44273 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pN1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3941
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PAiRFP2
  • Alt name
    Photoactivatable iRFP2
  • Species
    Synthetic
  • Insert Size (bp)
    1545
  • Mutation
    K69R/R83K/G120D/A123T/M163L/Q168E/R220P/S243N/V244F/G269D/A276V/Y280C/V294A/H303F/H333R/I336L/D349R/M351I/A386V/G409D/L419I/T469S/A487T/E494G
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer ggtaggcgtgtacggtgggag
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pPAiRFP2-N1 was a gift from Vladislav Verkhusha (Addgene plasmid # 44273 ; http://n2t.net/addgene:44273 ; RRID:Addgene_44273)

  • For your References section:

    Far-red light photoactivatable near-infrared fluorescent proteins engineered from a bacterial phytochrome. Piatkevich KD, Subach FV, Verkhusha VV. Nat Commun. 2013 Jul 10;4:2153. doi: 10.1038/ncomms3153. 10.1038/ncomms3153 PubMed 23842578
