pAM1954
(Plasmid #40250)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 40250 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pAM542
  • Total vector size (bp) 11000
  • Vector type
    Cyanobacteria cloning vector

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    GFPmut2
  • Species
    Anabaena sp. Strain PCC 7120
  • Insert Size (bp)
    800
  • Promoter n/a

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site n/a (unknown if destroyed)
  • 3′ cloning site n/a (unknown if destroyed)
  • 5′ sequencing primer n/a
  • 3′ sequencing primer n/a
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

gfp from pKEN2-GFPmut2 inserted into pAM542, which contains PrbcL on a shuttle vector.

HindIII-Klenow filled-BamHI fragment containing GFPmut2 was inserted into SacI-T4 blunted-BamHI digested pAM542. PrbcL promoter fragment drives GFPmut2.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAM1954 was a gift from Susan Golden (Addgene plasmid # 40250 ; http://n2t.net/addgene:40250 ; RRID:Addgene_40250)
  • For your References section:

    Heterocyst pattern formation controlled by a diffusible peptide. Yoon HS, Golden JW. Science. 1998 Oct 30;282(5390):935-8. 10.1126/science.282.5390.935 PubMed 9794762
