pEGFP-Akt-DD
(Plasmid #39536)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 39536 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Akt
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    1600
  • Mutation
    DD = T308D and S473D
  • Entrez Gene
    Akt1 (a.k.a. Akt, LTR-akt, PKB, PKB/Akt, PKBalpha, Rac)
  • Promoter CMV
  • Tags / Fusion Proteins
    • HA (N terminal on insert)
    • EGFP (N terminal on backbone)
    • 6G linker (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer EGFP-C
  • 3′ sequencing primer sv40pA-R
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFP-Akt-DD was a gift from Julian Downward (Addgene plasmid # 39536 ; http://n2t.net/addgene:39536 ; RRID:Addgene_39536)
  • For your References section:

    Akt/PKB localisation and 3' phosphoinositide generation at sites of epithelial cell-matrix and cell-cell interaction. Watton SJ, Downward J. Curr Biol. 1999 Apr 22;9(8):433-6. 10.1016/S0960-9822(99)80192-4 PubMed 10226029
