Addgene

pKS2311
(Plasmid #37835)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 37835 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pPD49.26
  • Backbone manufacturer
    Fire Lab
  • Backbone size w/o insert (bp) 3410
  • Total vector size (bp) 8884
  • Vector type
    Worm Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Pnhx-2cpl-1W32A;Y35A::YFP
  • Alt name
    PPM2
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    2626
  • Mutation
    W32A;Y35A
  • Entrez Gene
    cpl-1 (a.k.a. CELE_T03E6.7)
  • Promoter nhx-2
  • Tag / Fusion Protein
    • YFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site NheI (not destroyed)
  • 5′ sequencing primer CGCTCTCTCGTCTCTCTCTC
  • 3′ sequencing primer CGTGTCTTGTAGTTCCCGTCATC
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pKS2311 was a gift from Gary Silverman (Addgene plasmid # 37835 ; http://n2t.net/addgene:37835 ; RRID:Addgene_37835)

  • For your References section:

    A pro-cathepsin L mutant is a luminal substrate for endoplasmic-reticulum-associated degradation in C. elegans. Miedel MT, Graf NJ, Stephen KE, Long OS, Pak SC, Perlmutter DH, Silverman GA, Luke CJ. PLoS One. 2012;7(7):e40145. Epub 2012 Jul 2. 10.1371/journal.pone.0040145 PubMed 22768338
