pCA-G-intron(Neo)-T(LNL)
(Plasmid #36907)

• Depositing Lab: Liqun Luo
• Publication: Tasic et al PLoS One. 2012;7(3):e33332. Epub 2012 Mar 27.

Backbone

• Vector backbone: pBluescript SK(+)
• Backbone manufacturer: Stratagene
• Backbone size w/o insert (bp): 3000
• Total vector size (bp): 8787
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert 1

• Gene/Insert name: GFP
• Alt name: mut4EGFP
• Mutation: deleted nucleotides after nucleotide 274
• Promoter: CAG (chicken beta actin promoter and CMV enhancer)

Cloning Information for Gene/Insert 1

• Cloning method: Unknown
• 5′ sequencing primer: see sequence
• 3′ sequencing primer: see sequence

Gene/Insert 2

• Gene/Insert name: tdTomato-3Myc
• Alt name: tdT-3Myc
• Mutation: removed start codon
• Promoter: CAG (chicken beta actin promoter and CMV enhancer)
• Tag / Fusion Protein:
  • 3 Myc tags (C terminal on insert)

Cloning Information for Gene/Insert 2

• Cloning method: Unknown
• 5′ sequencing primer: see sequence
• 3′ sequencing primer: T3

Gene/Insert 3

• Gene/Insert name: beta-globin intron
• Mutation: insertion of loxP-Neo-loxP
• Promoter: CAG (chicken beta actin promoter and CMV enhancer)

Cloning Information for Gene/Insert 3

• Cloning method: Unknown
• 5′ sequencing primer: see sequence
• 3′ sequencing primer: see sequence

Gene/Insert 4

• Gene/Insert name: Neo
• Alt name: neomycin phosphotransferase
• Alt name: neomycin resistance gene
• Promoter: SV40

Cloning Information for Gene/Insert 4

• Cloning method: Unknown
• 5′ sequencing primer: see sequence
• 3′ sequencing primer: see sequence

Resource Information

• Supplemental Documents:
  • pCA-G-intron(Neo)-T(LNL)_GenBank_file
• A portion of this plasmid was derived from a plasmid made by: R. Tsien

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Takara Bio Limited Use Label License (formerly Clontech)
• Industry Terms:
  • Not Available to Industry

Depositor Comments

This is the 'LNL' version of the plasmid. It contains loxP-Neo-loxP in the intron. The 'FLLFLNL' version is also available from Addgene.
