pcDNA3.1 mycBioID
(Plasmid #35700)

• Purpose: To fuse your protein of interest to the C-terminus of BirA(R118G) and use in proximity-dependent biotin identification (BioID); myc tag
• Depositing Lab: Kyle Roux
• Publication: Roux et al J Cell Biol. 2012 Mar 12.

Backbone

• Vector backbone: pcDNA3.1(-)
• Backbone manufacturer: InVitrogen
• Backbone size w/o insert (bp): 5400
• Modifications to backbone: none
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): XL1 Blue
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: BirA
• Species: E. coli
• Insert Size (bp): 1116
• Mutation: R118G (highly promiscuous form)
• Promoter: cmv
• Tag / Fusion Protein:
  • Myc (N terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: NheI (not destroyed)
• 3′ cloning site: PmeI (not destroyed)
• 5′ sequencing primer: CMV-F
• 3′ sequencing primer: BGH-rev

Resource Information

• Addgene Notes:
  • Addgene diagnostic digest
• Articles Citing this Plasmid:
  • 84 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Information for Cloning Grade DNA (Catalog # 35700-DNA.cg) ( Back to top)

Purpose

Cloning grade DNA is suitable for use in PCR, cloning reactions, or transformation into E. coli. The purity and amount is not suitable for direct transfections.

Delivery

• Amount: 2 µg
• Guaranteed Concentration: 100 ng/µl +/- 5 ng/µl
• Pricing: $105 USD
• Storage: DNA can be stored at 4℃ (short term) or -20℃ (long term).

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Addgene has verified this plasmid using Next Generation Sequencing. Results are available here
