Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 34633 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepN1
-
Backbone manufacturerClontech
- Backbone size w/o insert (bp) 4013
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemTagBFP2
-
Insert Size (bp)702
-
MutationI174A compared to mTagBFP
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site AgeI (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer 5'-cggtaggcgtgtacggtgggag-3'
- 3′ sequencing primer 5'-gttcagggggaggtgtgggagg-3' (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pmTagBFP2-N1 was a gift from Vladislav Verkhusha (Addgene plasmid # 34633) -
For your References section:
An enhanced monomeric blue fluorescent protein with the high chemical stability of the chromophore. Subach OM, Cranfill PJ, Davidson MW, Verkhusha VV. PLoS One. 2011;6(12):e28674. Epub 2011 Dec 8. 10.1371/journal.pone.0028674 PubMed 22174863
