CaYin1
(Plasmid #33067)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 33067 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBAD hisB
  • Backbone manufacturer
    invitrogen
  • Backbone size w/o insert (bp) 4100
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    CaYin1
  • Alt name
    tdtomato mAmetrine1.2 FRET calcium sensor
  • Insert Size (bp)
    2617
  • GenBank ID
  • Promoter ARA promoter
  • Tag / Fusion Protein
    • 6 His tag (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho1 (not destroyed)
  • 3′ cloning site EcoR1 (not destroyed)
  • 5′ sequencing primer pBAD_fwd_primer
  • 3′ sequencing primer pBAD_rev_primer
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CaYin1 was a gift from Robert Campbell (Addgene plasmid # 33067 ; http://n2t.net/addgene:33067 ; RRID:Addgene_33067)

  • For your References section:

    Forster resonance energy transfer-based biosensors for multiparameter ratiometric imaging of Ca2+ dynamics and caspase-3 activity in single cells. Ding Y, Ai HW, Hoi H, Campbell RE. Anal Chem. 2011 Dec 15;83(24):9687-93. doi: 10.1021/ac202595g. Epub 2011 Nov 28. 10.1021/ac202595g PubMed 22080726
