pEntr-SRFflbio
(Plasmid #32971)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 32971 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEntr3c
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2700
  • Modifications to backbone
    see pEntr-flbio
  • Vector type
    gateway

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    SRF
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1500
  • Entrez Gene
    SRF (a.k.a. MCM1)
  • Tag / Fusion Protein
    • flag-bio (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site SpeI (not destroyed)
  • 5′ sequencing primer GGCATCAAACTAAGCAGAAG
  • 3′ sequencing primer GTAACATCAGAGATTTTGAGACAC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEntr-SRFflbio was a gift from William Pu (Addgene plasmid # 32971 ; http://n2t.net/addgene:32971 ; RRID:Addgene_32971)
  • For your References section:

    Co-occupancy by multiple cardiac transcription factors identifies transcriptional enhancers active in heart. He A, Kong SW, Ma Q, Pu WT. Proc Natl Acad Sci U S A. 2011 Apr 5. 108(14):5632-7. 10.1073/pnas.1016959108 PubMed 21415370
