pPIGA-PHD
(Plasmid #26778)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 26778 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCR2.1-TOPO
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 3931
  • Vector type
    Mammalian Expression
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PGK-Hyg-p(A)
  • Alt name
    Hygromycin resistant gene
  • Alt name
    PGK promoter
  • Insert Size (bp)
    2087
  • Entrez Gene
    PGK1 (a.k.a. YCR012W)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer M13-rev
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pPIGA-PHD was a gift from Linzhao Cheng (Addgene plasmid # 26778 ; http://n2t.net/addgene:26778 ; RRID:Addgene_26778)
  • For your References section:

    Gene targeting of a disease-related gene in human induced pluripotent stem and embryonic stem cells. Zou J, Maeder ML, Mali P, Pruett-Miller SM, Thibodeau-Beganny S, Chou BK, Chen G, Ye Z, Park IH, Daley GQ, Porteus MH, Joung JK, Cheng L. Cell Stem Cell. 2009 Jul 2. 5(1):97-110. 10.1016/j.stem.2009.05.023 PubMed 19540188
