Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 26772 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCS2
- Backbone size w/o insert (bp) 4000
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameTdTomato-2A-H2BGFP-SV40pA
-
Alt namemembrane red
-
Alt namehistone GFP
-
SpeciesAequorea victoria, Discosoma sp
-
Insert Size (bp)3233
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site XhoI (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer SP6
- 3′ sequencing primer M13 rev (Common Sequencing Primers)
Resource Information
-
Addgene Notes
-
A portion of this plasmid was derived from a plasmid made byShahragim Tajbakhsh, Roger Tsien and Sean Megason
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCS2-TAG was a gift from Shankar Srinivas (Addgene plasmid # 26772 ; http://n2t.net/addgene:26772 ; RRID:Addgene_26772) -
For your References section:
Use of the viral 2A peptide for bicistronic expression in transgenic mice. Trichas G, Begbie J, Srinivas S. BMC Biol. 2008 . 6():40. 10.1186/1741-7007-6-40 PubMed 18793381
