pLJM1 Flag Raptor
(Plasmid #26633)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 26633 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLJM1
  • Backbone manufacturer
    Available at Addgene (#19319)
  • Backbone size w/o insert (bp) 7400
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Growth instructions
    Grow in XL10Gold or Stbl3 cells to decrease recombination. Growing the cultures at 30C rather than 37 and in SOC sometimes helps with yield.
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    raptor
  • Species
    H. sapiens (human)
  • Entrez Gene
    RPTOR (a.k.a. KOG1, Mip1)
  • Tag / Fusion Protein
    • Flag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site BstBI (not destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLJM1 Flag Raptor was a gift from David Sabatini (Addgene plasmid # 26633 ; http://n2t.net/addgene:26633 ; RRID:Addgene_26633)

  • For your References section:

    Ragulator-Rag complex targets mTORC1 to the lysosomal surface and is necessary for its activation by amino acids. Sancak Y, Bar-Peled L, Zoncu R, Markhard AL, Nada S, Sabatini DM. Cell. 2010 Apr 16. 141(2):290-303. 10.1016/j.cell.2010.02.024 PubMed 20381137
