This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 26624 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepET28a
-
Backbone manufacturerNovagen
- Backbone size w/o insert (bp) 5247
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsTOP10F', 37oC
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameBirA
-
Alt namebiotin ligase
-
SpeciesE.coli
-
Insert Size (bp)967
-
Tag
/ Fusion Protein
- His (C terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Nco I (destroyed during cloning)
- 3′ cloning site Hind III (not destroyed)
- 5′ sequencing primer T7 (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
BirA gene was amplified from E.coli TOP10F' strain and subcloned into the pET28A vector.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
BirA in pET28a (w400-2) was a gift from Eric Campeau (Addgene plasmid # 26624 ; http://n2t.net/addgene:26624 ; RRID:Addgene_26624)
