Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 24295 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepEGFP-C1
-
Backbone manufacturerClontech
- Backbone size w/o insert (bp) 4700
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameautophagy related genes 14
-
Alt nameAtg14
-
SpeciesH. sapiens (human)
-
Insert Size (bp)1400
-
GenBank IDAK131251
-
Entrez GeneATG14 (a.k.a. ATG14L, BARKOR, KIAA0831)
-
Tag
/ Fusion Protein
- EGFP (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site EcoRI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer EGFP-C (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byFLJ16178,obtained from the Department of Biotechnology, National Institute of Technology and Evaluation, Tokyo, Japan
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pEGFP-C1-hAtg14 was a gift from Noboru Mizushima (Addgene plasmid # 24295 ; http://n2t.net/addgene:24295 ; RRID:Addgene_24295) -
For your References section:
Beclin 1 forms two distinct phosphatidylinositol 3-kinase complexes with mammalian Atg14 and UVRAG. Itakura E, Kishi C, Inoue K, Mizushima N. Mol Biol Cell. 2008 Dec . 19(12):5360-72. 10.1091/mbc.e08-01-0080 PubMed 18843052
