pQdCas12a.sggfp(A)
(Plasmid #236038)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 236038 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBBRMCS2
  • Backbone size w/o insert (bp) 3913
  • Total vector size (bp) 9761
  • Vector type
    CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    the plasmid is stable in both 30 and 37 centigrade in E. coli. the plasmid is stable in 30 centigrade in P. putida.
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    quorum sensing cassette luxI, luxR, and the LuxR-dependent promoter pLuxI , dCas12a and sgRNA design (A) of gfp gene
  • gRNA/shRNA sequence
    agatcagggctcgagcatggtgagcaagggcgaggagc
  • Promoter quorum sensing promoter

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer AGGATCTCGTCGTGACCCATG
  • 3′ sequencing primer AAACGGAGGAATGGGAACG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pQdCas12a.sggfp(A) was a gift from Radhakrishnan Mahadevan (Addgene plasmid # 236038 ; http://n2t.net/addgene:236038 ; RRID:Addgene_236038)
