pAtVPZv1.0
(Plasmid #233147)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 233147 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEarleyGate301
  • Vector type
    Plant Expression
  • Selectable markers
    BAR

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    Resistance to herbicide bialaphos
  • Alt name
    BAR resistance gene
  • Insert Size (bp)
    552
  • Promoter mas promoter

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    Zeaxanthin epoxidase
  • Alt name
    ZEP
  • Species
    A. thaliana (mustard weed)
  • Insert Size (bp)
    2004
  • Entrez Gene
    ABA1 (a.k.a. AT5G67030, ABA DEFICIENT 1, ARABIDOPSIS THALIANA ABA DEFICIENT 1, ARABIDOPSIS THALIANA ZEAXANTHIN EPOXIDASE, ATABA1, ATZEP, IBS3, IMPAIRED IN BABA-INDUCED STERILITY 3, K8A10.10, K8A10_10, LOS6, LOW EXPRESSION OF OSMOTIC STRESS-RESPONSIVE GENES 6, NON-PHOTOCHEMICAL QUENCHING 2, NPQ2, ZEAXANTHIN EPOXIDASE, ZEP)
  • Promoter Rbcs1a

Cloning Information for Gene/Insert 2

Gene/Insert 3

  • Gene/Insert name
    Photosystem II subunit S
  • Alt name
    PsbS
  • Species
    A. thaliana (mustard weed)
  • Insert Size (bp)
    798
  • Entrez Gene
    NPQ4 (a.k.a. AT1G44575, CP22, NONPHOTOCHEMICAL QUENCHING 4, PHOTOSYSTEM II SUBUNIT S, PSBS, PSII-S, T18F15.3, T18F15_3)
  • Promoter GAPA-1

Cloning Information for Gene/Insert 3

Gene/Insert 4

  • Gene/Insert name
    Violoxanthin de-epoxidase
  • Alt name
    VDE
  • Species
    A. thaliana (mustard weed)
  • Insert Size (bp)
    1389
  • Entrez Gene
    NPQ1 (a.k.a. AT1G08550, ARABIDOPSIS VIOLAXANTHIN DE-EPOXIDASE 1, AVDE1, F22O13.3, F22O13_3, VIOLAXANTHIN DE-EPOXIDASE PRECURSOR, non-photochemical quenching 1)
  • Promoter FBA-2

Cloning Information for Gene/Insert 4

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAtVPZv1.0 was a gift from Krishna Niyogi (Addgene plasmid # 233147 ; http://n2t.net/addgene:233147 ; RRID:Addgene_233147)

  • For your References section:

    Improving photosynthesis and crop productivity by accelerating recovery from photoprotection. Kromdijk J, Glowacka K, Leonelli L, Gabilly ST, Iwai M, Niyogi KK, Long SP. Science. 2016 Nov 18;354(6314):857-861. doi: 10.1126/science.aai8878. 10.1126/science.aai8878 PubMed 27856901
