pBY2887
(Plasmid #23221)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 23221 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pTriEx5
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 5050
  • Vector type
    Mammalian Expression, Bacterial Expression, Insect Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    SnAvi
  • Species
    artifical
  • Insert Size (bp)
    977

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer T7
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBY2887 was a gift from Ralf Baumeister (Addgene plasmid # 23221 ; http://n2t.net/addgene:23221 ; RRID:Addgene_23221)

  • For your References section:

    SnAvi - a new tandem tag for high-affinity protein-complex purification. Schaffer U, Schlosser A, Muller KM, Schafer A, Katava N, Baumeister R, Schulze E. Nucleic Acids Res. 2010 Jan 4. ():. 10.1093/nar/gkp1178 PubMed 20047968
