PC1575
(Plasmid #232088)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 232088 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone size w/o insert (bp) 5400
  • Total vector size (bp) 7285
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    uAb with cloning Esp3I restriction site
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1899
  • Promoter CMV
  • Tag / Fusion Protein
    • IRES-mCherry (N terminal on insert)

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.1101/2023.06.26.546591 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PC1575 was a gift from Pranam Chatterjee (Addgene plasmid # 232088 ; http://n2t.net/addgene:232088 ; RRID:Addgene_232088)

  • For your References section:

    De Novo Design of Peptide Binders to Conformationally Diverse Targets with Contrastive Language Modeling. Bhat S, Palepu K, Hong L, Mao J, Ye T, Iyer R, Zhao L, Chen T, Vincoff S, Watson R, Wang T, Srijay D, Kavirayuni VS, Kholina K, Goel S, Vure P, Desphande AJ, Soderling SH, DeLisa MP, Chatterjee P. Science Advances, 22 Jan 2025. Vol 11, Issue 4. DOI: 10.1126/sciadv.adr8638 10.1101/2023.06.26.546591 PubMed 39091799
