MKT071
(Plasmid #231995)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 231995 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    ColE1
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    MicF RNA toehold switch
  • Insert Size (bp)
    98
  • Promoter J23119

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    MKT071 was a gift from Melissa Takahashi (Addgene plasmid # 231995 ; http://n2t.net/addgene:231995 ; RRID:Addgene_231995)
  • For your References section:

    Improved RNA toehold switch sensitivity using the NanoLuc complementation reporter. Diaz KJ, Jarquin J, Petrosyan A, Takahashi MK. MicroPubl Biol. 2025 Jan 2;2025:10.17912/micropub.biology.001334. doi: 10.17912/micropub.biology.001334. eCollection 2025. 10.17912/micropub.biology.001334 PubMed 39839716
