pMX234
(Plasmid
#23006)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 23006 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCMV-M1
- Backbone size w/o insert (bp) 4004
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemRFP-CenpB
-
Alt nameCENP-B
-
Alt namecentromere autoantigen protein B
-
SpeciesCricetulus griseus
-
Insert Size (bp)1214
-
Mutationdeleted CenpB amino acids 169-606, T145S
-
GenBank IDU20951
-
Tag
/ Fusion Protein
- mRFP1.0 (N terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site EcoRI (not destroyed)
- 3′ cloning site SalI (not destroyed)
- 5′ sequencing primer CMV promoter (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pMX234 was a gift from Linda Wordeman (Addgene plasmid # 23006 ; http://n2t.net/addgene:23006 ; RRID:Addgene_23006) -
For your References section:
The kinesin-8 motor Kif18A suppresses kinetochore movements to control mitotic chromosome alignment. Stumpff J, von Dassow G, Wagenbach M, Asbury C, Wordeman L. Dev Cell. 2008 Feb . 14(2):252-62. 10.1016/j.devcel.2007.11.014 PubMed 18267093
