Bxb1-GT_AIO-TetOn_mNgn2 _Down-Tandem
(Plasmid #229795)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 229795 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBR322/pUC
  • Backbone size w/o insert (bp) 4700
  • Vector type
    Mammalian Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TRE-mNgn2; rtTA-T2A-mTagBFP2
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    5700
  • Entrez Gene
    Neurog2 (a.k.a. Atoh4, Math4A, bHLHa8, ngn-2, ngn2)
  • Promoter TRE and CAG
  • Tag / Fusion Protein
    • NLS (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.1101/2024.10.17.616637 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Bxb1-GT_AIO-TetOn_mNgn2 _Down-Tandem was a gift from Richard Davis (Addgene plasmid # 229795 ; http://n2t.net/addgene:229795 ; RRID:Addgene_229795)

  • For your References section:

    STRAIGHT-IN Dual: a platform for dual, single-copy integrations of DNA payloads and gene circuits into human induced pluripotent stem cells. Blanch-Asensio A, Ploessl DS, Wang NB, Mummery CL, Galloway KE, Davis RP. bioRxiv [Preprint]. 2024 Oct 17:2024.10.17.616637. doi: 10.1101/2024.10.17.616637. 10.1101/2024.10.17.616637 PubMed 39464154
