pGGA016
(Plasmid #228231)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 228231 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUC19
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    5xOp
  • Insert Size (bp)
    402

Cloning Information

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Ian Moore Lab

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGGA016 was a gift from Alexis Maizel (Addgene plasmid # 228231 ; http://n2t.net/addgene:228231 ; RRID:Addgene_228231)

  • For your References section:

    GreenGate 2.0: Backwards compatible addons for assembly of complex transcriptional units and their stacking with GreenGate. Piepers M, Erbstein K, Reyes-Hernandez J, Song C, Tessi T, Petrasiunaite V, Faerber N, Distel K, Maizel A. PLoS One. 2023 Sep 8;18(9):e0290097. doi: 10.1371/journal.pone.0290097. eCollection 2023. 10.1371/journal.pone.0290097 PubMed 37682951
