pMRX-IPU-SNAP-Omp25
(Plasmid #228137)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 228137 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMRX-IPU
  • Backbone size w/o insert (bp) 6101
  • Total vector size (bp) 6787
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Omp25
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    686
  • Mutation
    transmembrane region (C-terminus)
  • GenBank ID
    NM_022599.2
  • Entrez Gene
    Synj2bp (a.k.a. Omp25)
  • Tag / Fusion Protein
    • SNAP (N terminal on insert)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMRX-IPU-SNAP-Omp25 was a gift from Noboru Mizushima (Addgene plasmid # 228137 ; http://n2t.net/addgene:228137 ; RRID:Addgene_228137)

  • For your References section:

    Organelle landscape analysis using a multiparametric particle-based method. Kurikawa Y, Koyama-Honda I, Tamura N, Koike S, Mizushima N. PLoS Biol. 2024 Sep 17;22(9):e3002777. doi: 10.1371/journal.pbio.3002777. eCollection 2024 Sep. 10.1371/journal.pbio.3002777 PubMed 39288101
