qTAG-C-Solo-mStayGold-CLTC
(Plasmid
#227313)
-
PurposeDonor template for mStayGold insertion into the C-terminus of the CLTC locus. For clathrin heavy chain visualization. To be co-transfected with sgRNA px330-PITCh-CLTC (Addgene #227312)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 227313 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepUC19
-
Backbone manufacturerInvitrogen
- Backbone size w/o insert (bp) 2686
-
Vector typeMammalian Expression, CRISPR ; Donor Template
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCLTC Homology Arms flanking a mStayGold Tag
-
Alt nameCLTC
-
SpeciesH. sapiens (human)
-
Insert Size (bp)1847
-
Entrez GeneCLTC (a.k.a. CHC, CHC17, CLH-17, CLTCL2, Hc, MRD56)
- Promoter Promoterless
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer CTGCAAGGCGATTAAGTTGGGTAAC
- 3′ sequencing primer GGCTCGTATGTTGTGTGGAATTGT (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
To be co-transfected with sgRNA px330-PITCh-CLTC (Addgene #227312): https://www.addgene.org/227312/
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
qTAG-C-Solo-mStayGold-CLTC was a gift from Laurence Pelletier (Addgene plasmid # 227313 ; http://n2t.net/addgene:227313 ; RRID:Addgene_227313) -
For your References section:
qTAG: An adaptable CRISPR-based endogenous tagging protocol using optimized repair cassettes. Philip R, Sharma A, Matellan L, Erpf AC, Hsu W, Tkach JM, Wyatt HDM, Pelletier L. bioRxiv 10.1101/2023.11.01.565029
