pRGEB32-CrU6-2-35S
(Plasmid
#226706)
-
PurposeFor CRISPR/Cas-mediated gene editing in model fern species, Ceratopteris richardii; expresses guide RNAs from CrU6-2 promoter and Cas9 from CaMV 35S promoter.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 226706 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCambia1300
-
Vector typeCRISPR
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCrU6-2
-
SpeciesC. richardii
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Unknown (unknown if destroyed)
- 3′ cloning site Unknown (unknown if destroyed)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://doi.org/10.1101/2024.04.10.588889 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pRGEB32-CrU6-2-35S was a gift from Fenglin Deng (Addgene plasmid # 226706 ; http://n2t.net/addgene:226706 ; RRID:Addgene_226706) -
For your References section:
Efficient gene editing of a model fern species through gametophyte-based transformation. Jiang W, Deng F, Babla M, Chen C, Yang D, Tong T, Qin Y, Chen G, Marchant B, Soltis P, Soltis DE, Zeng F, Chen ZH. Plant Physiol. 2024 Sep 12:kiae473. doi: 10.1093/plphys/kiae473. 10.1093/plphys/kiae473 PubMed 39268871
