PM-ExRai-PKNAR(T/A)
(Plasmid #226634)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 226634 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    PM-ExRai-PKNAR(T/A)
  • Mutation
    Phosphorylatable Thr of PM-ExRai-PKNAR mutated to Ala

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Parent plasmid Exrai-AKAR2 was a gift from Jin Zhang lab

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PM-ExRai-PKNAR(T/A) was a gift from Ju Chen (Addgene plasmid # 226634 ; http://n2t.net/addgene:226634 ; RRID:Addgene_226634)

  • For your References section:

    Illuminating understudied kinases: a generalizable biosensor development method applied to protein kinase N. Bogomolovas J, Chen J. Commun Biol. 2025 Jan 22;8(1):109. doi: 10.1038/s42003-025-07510-4. 10.1038/s42003-025-07510-4 PubMed 39843538
