Mito-mEosEM-E
(Plasmid #226335)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 226335 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-N1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    COX8A
  • Alt name
    Cytochrome C oxidase, subunit 8-2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    186
  • Entrez Gene
    COX8A (a.k.a. COX, COX8, COX8-2, COX8L, MC4DN15, VIII, VIII-L)
  • Promoter CMV
  • Tag / Fusion Protein
    • mEosEM-E (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CMV Forward
  • 3′ sequencing primer SV40pA-R
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Mito-mEosEM-E was a gift from Pingyong Xu (Addgene plasmid # 226335 ; http://n2t.net/addgene:226335 ; RRID:Addgene_226335)

  • For your References section:

    Improved Fluorescent Proteins for Dual-Colour Post-Embedding CLEM. Peng D, Li N, He W, Drasbek KR, Xu T, Zhang M, Xu P. Cells. 2022 Mar 23;11(7):1077. doi: 10.3390/cells11071077. 10.3390/cells11071077 PubMed 35406640
