Flag-HA-UCHL1
(Plasmid #22563)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 22563 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pDEST_LTR_N_FLAG_HA_IRES_puro
  • Backbone manufacturer
    Harper_Lab
  • Backbone size w/o insert (bp) 6521
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    UCHL1
  • Alt name
    ubiquitin carboxyl-terminal esterase L1 (ubiquitin thiolesterase)
  • Alt name
    PARK5, PGP9.5, Uch-L1
  • Species
    H. sapiens (human)
  • Mutation
    None
  • GenBank ID
    BC005117
  • Entrez Gene
    UCHL1 (a.k.a. HEL-117, HEL-S-53, NDGOA, PARK5, PGP 9.5, PGP9.5, PGP95, SPG79, SPG79A, UCHL-1, Uch-L1)
  • Tags / Fusion Proteins
    • HA (N terminal on backbone)
    • FLAG (N terminal on backbone)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ cloning site GATEWAY_LR (unknown if destroyed)
  • 3′ cloning site GATEWAY_LR (unknown if destroyed)
  • 5′ sequencing primer CAGCCCTCACTCCTTCTCTAGG
  • 3′ sequencing primer CAAGCGGCTTCGGCCAGTAAC
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    MGC/Open
  • Articles Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Flag-HA-UCHL1 was a gift from Wade Harper (Addgene plasmid # 22563 ; http://n2t.net/addgene:22563 ; RRID:Addgene_22563)
  • For your References section:

    Defining the human deubiquitinating enzyme interaction landscape. Sowa ME, Bennett EJ, Gygi SP, Harper JW. Cell. 2009 Jul 23. 138(2):389-403. 10.1016/j.cell.2009.04.042 PubMed 19615732
