pFBOH-MHL.mEGFP-CBX8
(Plasmid #224710)

Print

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 224710 Standard format: Plasmid sent in bacteria as agar stab 1 $85 *
Add to Cart

* Log in to view industry pricing.

Backbone

  • Vector backbone
    pFBOH-MHL
  • Backbone manufacturer
    Structural Genomics Consortium
  • Backbone size w/o insert (bp) 5459
  • Total vector size (bp) 6626
  • Vector type
    Insect Expression
  • Selectable markers
    Gentamicin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CBX8
  • Alt name
    chromobox 8
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1167
  • GenBank ID
    57332
  • Entrez Gene
    CBX8 (a.k.a. PC3, RC1)
  • Promoter Polyhedrin
  • Tag / Fusion Protein
    • mEGFP (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer TGTACAAGAGTGGAAGTGAGCTT TCAGCGGTGGGG
  • 3′ sequencing primer CAAGCTTCGTCATCATCATCTTTT CTCTTTAAAAAAGCCT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFBOH-MHL.mEGFP-CBX8 was a gift from Chen Davidovich (Addgene plasmid # 224710 ; http://n2t.net/addgene:224710 ; RRID:Addgene_224710)

  • For your References section:

    Dynamic PRC1-CBX8 stabilizes a porous structure of chromatin condensates. Uckelmann M, Levina V, Taveneau C, Han Ng X, Pandey V, Martinez J, Mendiratta S, Houx J, Boudes M, Venugopal H, Trepout S, Zhang Q, Flanigan S, Li M, Sierecki E, Gambin Y, Das PP, Bell O, de Marco A, Davidovich C. bioRxiv [Preprint]. 2024 Feb 12:2023.05.08.539931. doi: 10.1101/2023.05.08.539931. 10.1101/2023.05.08.539931 PubMed 38405976
