p5E-EFS (EF1a core) (JDW 1319)
(Plasmid
#224474)
-
PurposeGateway compatible 5' entry clone with human alpha 2 globin pause site (to prevent transcription readthrough) and EF1a core promoter. Lacks downstream intron for a lower-activity, compact promoter.
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 224474 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepDONRP4-P1r
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameEFS promoter
-
SpeciesH. sapiens (human)
Cloning Information
- Cloning method Gateway Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://doi.org/10.1101/2024.07.13.603267 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
p5E-EFS (EF1a core) (JDW 1319) was a gift from Joshua Wythe (Addgene plasmid # 224474 ; http://n2t.net/addgene:224474 ; RRID:Addgene_224474) -
For your References section:
Multisite Assembly of Gateway Induced Clones (MAGIC): a flexible cloning toolbox with diverse applications in vertebrate model systems. Gillespie W, Zhang Y, Ruiz OE, Cerda III J, Ortiz-Guzman J, Turner WD, Largoza G, Sherman M, Mosser LE, Fujimoto E, Chien C-B, Kwan KM, Arenkiel BR, Devine WP, Wythe JD. bioRxiv 2024.07.13.603267 10.1101/2024.07.13.603267
