pCMV-PE7-mutant (Q20A_Y23A_Y24F_F35A)
(Plasmid #224123)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 224123 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCMV
  • Backbone size w/o insert (bp) 3402
  • Total vector size (bp) 10473
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PE7-mutant (Q20A_Y23A_Y24F_F35A)
  • Alt name
    PEmax-La(SSB)1-194-mutant (Q20A_Y23A_Y24F_F35A)
  • Species
    H. sapiens (human), Synthetic; SpCas9 is from Streptococcus pyogenes; MMLV_RT is from the Moloney murine leukemia virus; La(SSB)1-194 is from Homo sapiens
  • Insert Size (bp)
    7071
  • Mutation
    Q20A_Y23A_Y24F_F35A in La(SSB)1-194
  • Promoter CMV
  • Tags / Fusion Proteins
    • SV40 bpNLS (N terminal on insert)
    • SV40 bpNLS (C terminal on insert)
    • c-Myc NLS (C terminal on insert)

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMV-PE7-mutant (Q20A_Y23A_Y24F_F35A) was a gift from Brittany Adamson (Addgene plasmid # 224123 ; http://n2t.net/addgene:224123 ; RRID:Addgene_224123)

  • For your References section:

    Improving prime editing with an endogenous small RNA-binding protein. Yan J, Oyler-Castrillo P, Ravisankar P, Ward CC, Levesque S, Jing Y, Simpson D, Zhao A, Li H, Yan W, Goudy L, Schmidt R, Solley SC, Gilbert LA, Chan MM, Bauer DE, Marson A, Parsons LR, Adamson B. Nature. 2024 Apr 3. doi: 10.1038/s41586-024-07259-6. 10.1038/s41586-024-07259-6 PubMed 38570691
