pCambia-dLB-kanR-GFP
(Plasmid
#223177)
-
Purpose(Empty Backbone) Plant Transformation Vector that allows marker removal through Mendelian inheritance. Start of DNA transfer at RB, terminates at left border but in ~1/3 of cases goes ahead until second left border
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 223177 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 * |
* Log in to view industry pricing.
Backbone
-
Vector backbonepCambia
-
Backbone manufacturerCambia Foundation
- Backbone size (bp) 8995
-
Vector typePlant Expression ; Ti plasmid for Agrobacterium
-
Selectable markersKanamycin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth TemperatureRoom Temperature
-
Growth Strain(s)DH5alpha
-
Growth instructionsCan grow in E. coli (high copy) but also in Agrobacterium (low copy), as normal pCambia vectors. Selection is kanamycin-containing LB in E. coli and Agrobacterium
-
Copy numberHigh Copy
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made bySynthetic DNA
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Agrobacterium preferentially starts Ti-DNA transfer at the Right Border, and terminates at the Left Border. In a significant number of transfer events, however, the Left Border does not terminate and DNA transfer sequence is continued.
Based upon the paper:
Huang S, Gilbertson LA, Adams TH, Malloy KP, Reisenbigler EK, Birr DH, Snyder MW, Zhang Q, Luethy MH. Generation of marker-free transgenic maize by regular two-border Agrobacterium transformation vectors. Transgenic Res. 2004 Oct;13(5):451-61. doi: 10.1007/s11248-004-1453-3. PMID: 15587269.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCambia-dLB-kanR-GFP was a gift from Andreas Stuermer (Addgene plasmid # 223177 ; http://n2t.net/addgene:223177 ; RRID:Addgene_223177)
