pLN34 - pBait-5GC[1xMS2]-McaS
(Plasmid #222403)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 222403 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCDF
  • Backbone size w/o insert (bp) 3892
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    McaS
  • Species
    E. coli
  • Insert Size (bp)
    94
  • Entrez Gene
    mcaS (a.k.a. b4426, ECK1336, IS061, isrA)
  • Promoter pBAD
  • Tag / Fusion Protein
    • 1xMS2 hairpin, 5GC clamp

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XmaI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer CCGGTAACCCCGCTTATTAAAAGC
  • 3′ sequencing primer TATCAGACCGCTTCTGCGTTC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLN34 - pBait-5GC[1xMS2]-McaS was a gift from Katherine Berry (Addgene plasmid # 222403 ; http://n2t.net/addgene:222403 ; RRID:Addgene_222403)

  • For your References section:

    Improved constructs for bait RNA display in a bacterial three-hybrid assay. Linh D. Nguyen , Hannah LeBlanc & Katherine E. Berry. Sci Rep 15, 3820 (2025) 10.1038/s41598-024-85082-9
