pCAGGS-PHOSPHO2-TEV-Twin-Strep
(Plasmid #222016)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 222016 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCAGGS-N-TEV-Twin-Strep
  • Backbone manufacturer
    Chiaki Murakami
  • Backbone size w/o insert (bp) 4871
  • Total vector size (bp) 5596
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PHOSPHO2
  • Alt name
    phosphatase, orphan 2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    723
  • Mutation
    deleted stop codon (TAA)
  • GenBank ID
    NM_001008489.4
  • Entrez Gene
    PHOSPHO2
  • Promoter chicken β-actin promoter
  • Tags / Fusion Proteins
    • TEV cleavable site (C terminal on backbone)
    • Twin-Strep-tag (C terminal on backbone)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer TTCGGCTTCTGGCGTGTGACC
  • 3′ sequencing primer TATTAGCCAGAAGTCAGATGCTCAAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The insert can be removed using the restriction enzyme, XhoI.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCAGGS-PHOSPHO2-TEV-Twin-Strep was a gift from Chiaki Murakami (Addgene plasmid # 222016 ; http://n2t.net/addgene:222016 ; RRID:Addgene_222016)
