pCMV-SEMPER_GGG-msfGFP[r5M]_ACC-mEBFP2_IRES-mCherry
(Plasmid
#221076)
-
PurposeSEMPER plasmid for expression of msfGFP[r5M] and mEBFP2 in ratios dictated by the trinucleotide TIS. Relative ORF expression is characterized in publication
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 221076 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneCMV Sport
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameGGG-msfGFP[r5M]_ACC-mEBFP2_IRES-mCherry
-
SpeciesSynthetic
- Promoter CMV
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
This is a polycistronic expression insert. Please visit https://doi.org/10.1101/2023.05.26.541240 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCMV-SEMPER_GGG-msfGFP[r5M]_ACC-mEBFP2_IRES-mCherry was a gift from Mikhail Shapiro (Addgene plasmid # 221076 ; http://n2t.net/addgene:221076 ; RRID:Addgene_221076) -
For your References section:
SEMPER: Stoichiometric expression of mRNA polycistrons by eukaryotic ribosomes for compact, ratio-tunable multi-gene expression. Duan M, Dev I, Lu A, Ayrapetyan G, You MY, Shapiro MG. Cell Syst. 2024 Jul 17;15(7):597-609.e4. doi: 10.1016/j.cels.2024.06.001. Epub 2024 Jul 5. 10.1016/j.cels.2024.06.001 PubMed 38971149
