pBABE
(Plasmid #21836)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 21836 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pBABE-puro
  • Backbone size w/o insert (bp) 4569
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers
    EGFP

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    EGFP
  • Insert Size (bp)
    874
  • Tag / Fusion Protein
    • farnysylation signal (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (destroyed during cloning)
  • 3′ cloning site ClaI (not destroyed)
  • 5′ sequencing primer SV40pro-F
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The Puro resistance gene of pBABE puro was removed by Hind3-Cla1 digestion and replaced by the CDS of a EGFP that has a farnysylation signal in its C-term. The membrane association of EGFP is instrumental in detecting the protein in FACScan procedures that would otherwise lead to loss of GFP fluorescence.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBABE was a gift from David Ron (Addgene plasmid # 21836 ; http://n2t.net/addgene:21836 ; RRID:Addgene_21836)
