AIRAP 2: AIRAP(m1.9-T7)pGEX.KG
(Plasmid
#21792)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 21792 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepGEX.KG
-
Backbone manufacturerATCC
- Backbone size w/o insert (bp) 5006
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)BL21
-
Growth instructionsStrain should be BL21
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameAIRAP
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)1250
-
GenBank IDAF224494
-
Entrez GeneZfand2a (a.k.a. Airap, AA407930, AU016206)
-
Tag
/ Fusion Protein
- GST (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (unknown if destroyed)
- 3′ cloning site XbaI (unknown if destroyed)
- 5′ sequencing primer pGEX-5
- 3′ sequencing primer pGEX-3 (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
We DO NOT have a good record for how this plasmid was constructed.
The best guess is that Jin Liu used the m1.9Bam.1S primer and T7
to PCR the CDS + 3'UTR from m1.9pBS and ligated the BamH1-Xba1
fragment in frame with GST in pGEX.KG
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
AIRAP 2: AIRAP(m1.9-T7)pGEX.KG was a gift from David Ron (Addgene plasmid # 21792 ; http://n2t.net/addgene:21792 ; RRID:Addgene_21792) -
For your References section:
An arsenite-inducible 19S regulatory particle-associated protein adapts proteasomes to proteotoxicity. Stanhill A, Haynes CM, Zhang Y, Min G, Steele MC, Kalinina J, Martinez E, Pickart CM, Kong XP, Ron D. Mol Cell. 2006 Sep 15. 23(6):875-85. 10.1016/j.molcel.2006.07.023 PubMed 16973439
