pNES-PRKCZ-C20-EGFP (C-NES-PRKCZ-C20)
(Plasmid #217763)

Print

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 217763 Standard format: Plasmid sent in bacteria as agar stab 1 $85 *
Add to Cart

* Log in to view industry pricing.

Backbone

  • Vector backbone
    pEGFP-N1
  • Backbone manufacturer
    Clonetech
  • Backbone size w/o insert (bp) 4600
  • Total vector size (bp) 4978
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Protein kinase C zeta
  • Alt name
    PRKCZ
  • Alt name
    PKC2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    560
  • Mutation
    NES (ALQKKLEELELDEAPVAT) plus C20 domain (aa 405-592)
  • GenBank ID
    NM_002744.6
  • Entrez Gene
    PRKCZ (a.k.a. PKC-ZETA, PKC2)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (C terminal on backbone)

Cloning Information

  • Cloning method Other
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer GGTTCAGGGGGAGGTGTG
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNES-PRKCZ-C20-EGFP (C-NES-PRKCZ-C20) was a gift from Paula Nunes-Hasler (Addgene plasmid # 217763 ; http://n2t.net/addgene:217763 ; RRID:Addgene_217763)

  • For your References section:

    Development of Genetically Encoded Fluorescent KSR1-Based Probes to Track Ceramides during Phagocytosis. Girik V, van Ek L, Dentand Quadri I, Azam M, Cruz Cobo M, Mandavit M, Riezman I, Riezman H, Gavin AC, Nunes-Hasler P. Int J Mol Sci. 2024 Mar 5;25(5):2996. doi: 10.3390/ijms25052996. 10.3390/ijms25052996 PubMed 38474242
