pGL4.10/RSV_XS3B-miniXon_Luciferase
(Plasmid #217302)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 217302 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGL4.10
  • Backbone size w/o insert (bp) 4666
  • Total vector size (bp) 5257
  • Vector type
    Mammalian Expression, Luciferase

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    XS3B-miniXon
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    591
  • Mutation
    Kozak ATG initiation sequence in middle exon
  • Promoter RSV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer TCCCGTCTTCGAGTGGGTA
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGL4.10/RSV_XS3B-miniXon_Luciferase was a gift from Beverly L. Davidson (Addgene plasmid # 217302 ; http://n2t.net/addgene:217302 ; RRID:Addgene_217302)
