pMVV103
(Plasmid
#215309)
-
PurposeExpresses sfGFP under induction with the aTc Marionette Cassette (TetR + PTet-sfGFP) with a BBR1 backbone.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 215309 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneBBR1
- Backbone size w/o insert (bp) 4000
- Total vector size (bp) 4749
-
Modifications to backboneConstitutive TetR expression
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert namesfGFP
-
SpeciesSynthetic
-
Insert Size (bp)711
- Promoter Ptet
-
Tag
/ Fusion Protein
- None
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer na (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byOptimized induction cassettes were cloned from the Marionette sensor collection into broad host origin BBR1: https://www.addgene.org/kits/marionette-sensor-collection/ https://doi.org/10.1038/s41589-018-0168-3
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pMVV103 was a gift from Brian Pfleger (Addgene plasmid # 215309 ; http://n2t.net/addgene:215309 ; RRID:Addgene_215309) -
For your References section:
Synthetic Biology Toolbox for Nitrogen-Fixing Soil Microbes. Venkataraman M, Ynigez-Gutierrez A, Infante V, MacIntyre A, Fernandes-Junior PI, Ane JM, Pfleger B. ACS Synth Biol. 2023 Dec 15;12(12):3623-3634. doi: 10.1021/acssynbio.3c00414. Epub 2023 Nov 21. 10.1021/acssynbio.3c00414 PubMed 37988619
