B2396_BTB-EGFP
(Plasmid #215099)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 215099 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    EGFPN1
  • Backbone manufacturer
    Clontech
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    BTB-EGFP
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1179
  • GenBank ID
    NM_001706.5
  • Entrez Gene
    BCL6 (a.k.a. BCL5, BCL6A, LAZ3, ZBTB27, ZNF51)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    B2396_BTB-EGFP was a gift from Chandra Tucker (Addgene plasmid # 215099 ; http://n2t.net/addgene:215099 ; RRID:Addgene_215099)

  • For your References section:

    A platform to induce and mature biomolecular condensates using chemicals and light. Hernandez-Candia CN, Brady BR, Harrison E, Tucker CL. Nat Chem Biol. 2024 Jan 8. doi: 10.1038/s41589-023-01520-1. 10.1038/s41589-023-01520-1 PubMed 38191942
