SpyTag-RBD Delta
(Plasmid #214723)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 214723 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5568
  • Total vector size (bp) 6312
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Receptor-Binding Domain
  • Alt name
    RBD
  • Species
    SARS-CoV-2
  • Insert Size (bp)
    741
  • Entrez Gene
    S (a.k.a. GU280_gp02, spike glycoprotein)
  • Promoter CMV
  • Tag / Fusion Protein
    • SpyTag (N terminal on insert)

Cloning Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    SpyTag-RBD Delta was a gift from Mark Howarth (Addgene plasmid # 214723 ; http://n2t.net/addgene:214723 ; RRID:Addgene_214723)

  • For your References section:

    Proactive vaccination using multiviral Quartet Nanocages to elicit broad anti-coronavirus responses. Hills RA, Tan TK, Cohen AA, Keeffe JR, Keeble AH, Gnanapragasam PNP, Storm KN, Rorick AV, West AP Jr, Hill ML, Liu S, Gilbert-Jaramillo J, Afzal M, Napier A, Admans G, James WS, Bjorkman PJ, Townsend AR, Howarth MR. Nat Nanotechnol. 2024 May 6. doi: 10.1038/s41565-024-01655-9. 10.1038/s41565-024-01655-9 PubMed 38710880
