delCMV-mCitrine
(Plasmid #214144)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 214144 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pmCitrine-N1
  • Total vector size (bp) 4279
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mCitrine
  • Species
    Aequorea victoria
  • Insert Size (bp)
    714
  • Promoter delCMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AseI (not destroyed)
  • 3′ cloning site BsrGI (not destroyed)
  • 5′ sequencing primer whole plasmid sequencing
    • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Robert Campbell & Michael Davidson & Oliver Griesbeck & Roger Tsien (Addgene plasmid # 54594)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

the delCMV promotor was derived from Watanabe and Mitchison, 2002, Science, 295:1083

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    delCMV-mCitrine was a gift from Leif Dehmelt (Addgene plasmid # 214144 ; http://n2t.net/addgene:214144 ; RRID:Addgene_214144)

  • For your References section:

    Rho GTPase activity crosstalk mediated by Arhgef11 and Arhgef12 coordinates cell protrusion-retraction cycles. Nanda S, Calderon A, Sachan A, Duong TT, Koch J, Xin X, Solouk-Stahlberg D, Wu YW, Nalbant P, Dehmelt L. Nat Commun. 2023 Dec 15;14(1):8356. doi: 10.1038/s41467-023-43875-y. 10.1038/s41467-023-43875-y PubMed 38102112
