pLD564 human L1 ORF2p-3xFlag (L1RP, CMV promoter) in pCEP4 Puro
(Plasmid #213030)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 213030 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCEP4 Puro
  • Backbone manufacturer
    Invitrogen (modified)
  • Backbone size w/o insert (bp) 9994
  • Total vector size (bp) 16226
  • Modifications to backbone
    Replacement of stock hygromycin with puromycin
  • Vector type
    Mammalian Expression
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Human LINE-1 (L1RP Sequence) with 5' UTR and ORF2-3xFlag
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    6232
  • GenBank ID
    AF148856.1
  • Promoter CMV
  • Tag / Fusion Protein
    • 3xFlag (ORF2p) (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NotI (not destroyed)
  • 3′ cloning site PmeI (destroyed during cloning)
  • 5′ sequencing primer CMV_Forward
  • 3′ sequencing primer SV40pA-Rev
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLD564 human L1 ORF2p-3xFlag (L1RP, CMV promoter) in pCEP4 Puro was a gift from Martin S. Taylor (Addgene plasmid # 213030 ; http://n2t.net/addgene:213030 ; RRID:Addgene_213030)

  • For your References section:

    Structures, functions and adaptations of the human LINE-1 ORF2 protein. Baldwin ET, van Eeuwen T, Hoyos D, Zalevsky A, Tchesnokov EP, Sanchez R, Miller BD, Di Stefano LH, Ruiz FX, Hancock M, Isik E, Mendez-Dorantes C, Walpole T, Nichols C, Wan P, Riento K, Halls-Kass R, Augustin M, Lammens A, Jestel A, Upla P, Xibinaku K, Congreve S, Hennink M, Rogala KB, Schneider AM, Fairman JE, Christensen SM, Desrosiers B, Bisacchi GS, Saunders OL, Hafeez N, Miao W, Kapeller R, Zaller DM, Sali A, Weichenrieder O, Burns KH, Gotte M, Rout MP, Arnold E, Greenbaum BD, Romero DL, LaCava J, Taylor MS. Nature. 2024 Feb;626(7997):194-206. doi: 10.1038/s41586-023-06947-z. Epub 2023 Dec 14. 10.1038/s41586-023-06947-z PubMed 38096902
